Doosan
Komatsu
PC20R-8
Mini Excavator
47 specifications
1 / 5
Image 1 of 5
Specifications
34 data points
Operating Specifications
| Operating Weight | 6,260 lb |
|---|---|
| Fuel Capacity | 9.3 gal |
| Hydraulic Pump Flow Capacity | 8.8 gal/min |
| Hydraulic System Fluid Capacity | 14.1 gal |
| Hydraulic System Relief Valve Pressure | 2,849 psi |
| Operating Voltage | 12 V |
| Alternator Supplied Amperage | 35 A |
| Engine Oil Capacity | 1.7 gal |
| Cooling System Fluid Capacity | 1.9 gal |
Engine
| Engine Model | 3LD1 |
|---|---|
| Displacement | 90 in³ |
| Gross Power | 24.8 hp |
| Net Power | 24.1 hp |
| Aspiration | natural |
| Max Torque | 69 lb-ft |
Dimensions
| Ground Clearance | 12 in |
|---|---|
| Height - Top of Cab | 93 in |
| Length of Track on Ground | 57 in |
| Tail Swing Radius | 54 in |
| Width to Outside of Tracks | 57 in |
| Removal Counterweight Clearance | 22 in |
Undercarriage
| Ground Pressure | 4 psi |
|---|---|
| Number of Track Rollers per Side | 3 |
| Max Travel Speed | 2.4 mph |
| Shoe Size | 12 in |
Boom/Stick Excavator Option 1
| Max Digging Depth | 102 in |
|---|---|
| Max Reach Along Ground | 172 in |
| Max Vertical Wall Digging Depth | 66 in |
| Max Loading Height | 113 in |
| Shipping Length of Unit | 174 in |
| Max Cutting Height | 166 in |
| Shipping Height of Unit | 56 in |
Bucket
| Reference Bucket Capacity | 0.10 yd³ |
|---|
Swing Mechanism
| Swing Speed | 8 rpm |
|---|
