Doosan
New Holland
E200SR
Excavator
44 specifications
1 / 5
Image 1 of 5
Specifications
52 data points
Operating Specifications
| Operating Weight | 31,967 lb |
|---|---|
| Fuel Capacity | 74.0 gal |
| Hydraulic Pump Flow Capacity | 85.6 gal/min |
| Hydraulic System Fluid Capacity | 44.4 gal |
| Hydraulic System Relief Valve Pressure | 4,978 psi |
| Engine Oil Capacity | 5.1 gal |
| Cooling System Fluid Capacity | 8.2 gal |
| Operating Voltage | 24 V |
| Alternator Supplied Amperage | 60 A |
| Hydraulic Pump Type | 2x piston |
| Tire Size | 9.00-20-14PR |
Engine
| Engine Model | DB58TIS |
|---|---|
| Displacement | 353 in³ |
| Power Measured @ | 2,200 rpm |
| Net Power | 128.0 hp |
| Number of Cylinders | 6 |
| Torque Measured @ | 1,600 rpm |
| Net Torque | 362 lb-ft |
Dimensions
| Ground Clearance | 15 in |
|---|---|
| Height - Top of Cab | 124 in |
| Wheelbase | 110 in |
| Overall Width | 8 in |
| Tail Swing Radius | 88 in |
| Upper Structure Clearance | 49 in |
Transmission
| Max Travel Speed | 23.0 mph |
|---|---|
| Transmission Type | Hydrostatic |
| Number of Forward Gears | 2 |
| Number of Reverse Gears | 2 |
Bucket
| Reference Bucket Capacity | 0.60 yd³ |
|---|---|
| Maximum Bucket Capacity | 0.90 yd³ |
| Minimum Bucket Capacity | 0.41 yd³ |
Swing Mechanism
| Swing Speed | 13 rpm |
|---|
Boom/Stick Mobile Excavator Option 1
| Max Digging Depth | 199 in |
|---|---|
| Max Cutting Height | 340 in |
| Max Reach Along Ground | 317 in |
| Max Loading Height | 245 in |
| Shipping Length of Unit | 291 in |
| Shipping Height of Unit | 151 in |
| Max Vertical Wall Dig Depth | 176 in |
Boom/Stick Mobile Excavator Option 2
| Max Digging Depth | 219 in |
|---|---|
| Max Cutting Height | 352 in |
| Max Reach Along Ground | 336 in |
| Max Loading Height | 257 in |
| Shipping Height of Unit | 151 in |
| Shipping Length of Unit | 291 in |
| Max Vertical Wall Dig Depth | 215 in |
Boom/Stick Mobile Excavator Option 3
| Max Digging Depth | 216 in |
|---|---|
| Max Cutting Height | 377 in |
| Max Reach Along Ground | 337 in |
| Max Loading Height | 281 in |
| Shipping Height of Unit | 151 in |
| Shipping Length of Unit | 289 in |
