Doosan
JCB
JS240L
Excavator
13 specifications
1 / 5
Image 1 of 5
Specifications
26 data points
Operating Specifications
| Operating Weight | 52,000 lb |
|---|---|
| Fuel Capacity | 92.5 gal |
| Hydraulic Pump Flow Capacity | 113.6 gal/min |
| Hydraulic System Fluid Capacity | 63.5 gal |
| Hydraulic System Relief Valve Pressure | 4,690 psi |
| Engine Oil Capacity | 5.1 gal |
| Cooling System Fluid Capacity | 11.1 gal |
| Swing Drive Fluid Capacity | 1.4 gal |
Engine
| Engine Model | DB58TIS |
|---|---|
| Displacement | 353 in³ |
| Power Measured @ | 1,950 rpm |
| Net Power | 148.0 hp |
Dimensions
| Ground Clearance | 19 in |
|---|---|
| Height - Top of Cab | 119 in |
| Length of Track on Ground | 144 in |
| Tail Swing Radius | 109 in |
| Width to Outside of Tracks | 119 in |
| Removal Counterweight Clearance | 44 in |
Undercarriage
| Ground Pressure | 7 psi |
|---|---|
| Track Gauge | 95 in |
| Shoe Size | 24 in |
Boom/Stick Excavator Option 1
| Max Digging Depth | 459 in |
|---|---|
| Max Reach Along Ground | 602 in |
| Max Loading Height | 430 in |
| Max Vertical Wall Digging Depth | 426 in |
| Max Cutting Height | 522 in |
