Dynapac
BOMAG
BW 154 AD-5
Smooth Drum Roller
37 specifications
1 / 5
Image 1 of 5
Specifications
36 data points
Operating Specifications
| Operating Weight | 30,424 lb |
|---|---|
| Operating weight ROPS | 26,235 lb |
| Max Speed | 7.5 mph |
| Fuel Capacity | 272.0 gal |
| Operating Width | 92 in |
| Tire Size | 23.1 x 26 AW |
| DEF tank capacity | 5.3 gal |
Engine
| Engine Model | QSF3.8 |
|---|---|
| Power Measured @ | 2,200 rpm |
| Gross Power | 130.1 hp |
| Engine Make | Cummins |
| Make | Cummins QSB4.5 T4i |
| Engine Type | Water cooled turbo charged + Intercooler |
Dimensions
| Ground Clearance | 18 in |
|---|---|
| Wheelbase | 118 in |
| Overall Length | 236 in |
| Height - Top of ROPS/FOPS | 114 in |
| Gradeability | 55.0 % |
| Height | 84 in |
| Turning Radius - Outside | 215 in |
| Curb clearance | 18 in |
| Overhang Rear | 4 in |
| Overhang Front | 4 in |
General Specifications
| Engine type | Cummins QSF 3.8 (T4f) — Starting 2019 Model Year |
|---|---|
| DRUM WIDTH IN. (CM) | 84 (213) — Starting 2019 Model Year |
| INSIDE TURN RADIUS IN. (CM) | 132 (335) — Starting 2019 Model Year |
| WIDTH IN. (CM) | 92 (233) — Starting 2019 Model Year |
| FREQUENCY HZ | 1,860/2,040 vpm — Starting 2019 Model Year |
Drum
| Drum Diameter | 60 in |
|---|---|
| Nominal Amplitude - High | 0 in |
| Centrifugal Force - High | 62,947 lb |
| Static Linear Load | 17 lb-ft |
| Vibration Frequency | 31 – 34 vpm |
| Centrifugal Force - Low | 38,218 lb |
| Nominal Amplitude - Low | 0 in |
| Drum thickness | 1 in |
