Dynapac
Hamm
3410P
Padfoot Compactor
31 specifications
1 / 5
Image 1 of 5
Specifications
33 data points
Operating Specifications
| Operating Weight | 27,337 lb |
|---|---|
| Operating weight ROPS | 26,235 lb |
| Max Speed | 7.5 mph |
| Fuel Capacity | 272.0 gal |
| Operating Width | 92 in |
| Tire Size | 23.1 x 26 TR |
| DEF tank capacity | 5.3 gal |
Engine
| Engine Model | QSF3.8 |
|---|---|
| Power Measured @ | 2,200 rpm |
| Gross Power | 130.1 hp |
| Engine Make | Cummins |
| Make | Cummins QSB4.5 T4i |
| Engine Type | Water cooled turbo charged + Intercooler |
Dimensions
| Ground Clearance | 18 in |
|---|---|
| Wheelbase | 118 in |
| Overall Length | 236 in |
| Height - Top of ROPS/FOPS | 118 in |
| Gradeability | 55.0 % |
| Height | 84 in |
| Turning Radius - Outside | 215 in |
| Curb clearance | 18 in |
| Overhang Rear | 4 in |
| Overhang Front | 4 in |
Drum
| Centrifugal Force - High | 58,450 lb |
|---|---|
| Drum Diameter | 59 in |
| Nominal Amplitude - High | 0 in |
| Pad Height | 4 in |
| Centrifugal Force - Low | 33,721 lb |
| Nominal Amplitude - Low | 0 in |
| Pad Surface Area | 23 in³ |
| Vibration Frequency | 30 vpm |
| Drum thickness | 1 in |
| Static Linear Load | 17 lb-ft |
