Dynapac
Ingersoll Rand
DD14S
Smooth Drum Roller
17 specifications
1 / 5
Image 1 of 5
Specifications
31 data points
Operating Specifications
| Operating Weight | 2,900 lb |
|---|---|
| Operating weight ROPS | 2,800 lb |
| Max Speed | 5.0 mph |
| Fuel Capacity | 6.0 gal |
| Oscillating angle | 13 ° |
| Steering Angle | 34 ° |
| Water Spray System Fluid Capacity | 50.0 gal |
Engine
| Engine Model | GX630R QYD |
|---|---|
| Power Measured @ | 3,000 rpm |
| Gross Power | 19.0 hp |
| Engine Make | Honda |
Dimensions
| Ground Clearance | 10 in |
|---|---|
| Height - Top of Cab | 91 in |
| Wheelbase | 53 in |
| Overall Length | 83 in |
| Overall Width | 39 in |
| Turning Radius - Inside | 72 in |
| Gradeability | 35.0 % |
| Turning Radius - Outside | 108 in |
| Curb clearance | 18 in |
| Overhang Front | 2 in |
| Overhang Rear | 2 in |
Brakes & Steering
| Service brake | Hydrostatic in forward and reverse lever |
|---|---|
| Parking brake | Failsafe brake in both drums |
Drum
| Drum Width | 35 in |
|---|---|
| Drum Diameter | 23 in |
| Vibration Frequency 1 | 70 vpm |
| Nominal Amplitude - High | 0 in |
| Centrifugal Force - High | 3,800 lb |
| Static Linear Load | 3 lb-ft |
| Drum thickness | 0 in |
