Grove
RT625
Rough Terrain Crane
38 specifications
1 / 5
Image 1 of 5
Specifications
33 data points
Operating Specifications
| Operating Weight | 41,844 lb |
|---|---|
| Tire Size | 14.00 x 24-16 PR |
| Operating Voltage | 12 V |
| Alternator Supplied Amperage | 62 A |
Engine
| Engine Model | S6D102E-1 |
|---|---|
| Displacement | 359 in³ |
| Power Measured @ | 2,500 rpm |
| Net Power | 121.0 hp |
| Number of Cylinders | 6 |
| Aspiration | Turbocharged |
| Torque Measured @ | 1,200 rpm |
| Max Torque | 368 lb-ft |
| Engine Make | Komatsu |
| Stroke | 5 in |
| Bore | 4 in |
| Fuel Type | Diesel |
Dimensions
| Wheelbase | 108 in |
|---|---|
| Transport Width | 96 in |
| Transport Height | 133 in |
| Transport Length | 355 in |
| Width w/ Outriggers Extended | 172 in |
| Carrier/Base Length | 203 in |
Transmission
| Max Speed - Forward | 26.5 mph |
|---|---|
| Max Speed - Reverse | 26.5 mph |
| Transmission Type | Powershift |
Boom
| Max Lift Capacity | 30,001 lb |
|---|---|
| Max Height @ Max Raise Angle - no jib | 720 in |
| Min Height @ Max Raise Angle | 240 in |
| Max Elevating Angle | 70 ° |
| Number of Sections | 4 |
| Swing Speed | 4 rpm |
| Min Operating Radius | 120 in |
| Max Operating Radius | 720 in |
