Gehl
Komatsu
PC20R-8
Mini Excavator
47 specifications
1 / 5
Image 1 of 5
Specifications
33 data points
Operating Specifications
| Operating Weight | 4,447 lb |
|---|---|
| Fuel Capacity | 6.4 gal |
| Hydraulic Pump Flow Capacity | 18.7 gal/min |
| Hydraulic System Fluid Capacity | 5.6 gal |
| Hydraulic System Relief Valve Pressure | 2,900 psi |
| Operating Voltage | 12 V |
| Alternator Supplied Amperage | 45 A |
Engine
| Engine Model | 3TNE 74 |
|---|---|
| Displacement | 61 in³ |
| Power Measured @ | 2,200 rpm |
| Net Power | 23.7 hp |
| Number of Cylinders | 3 |
Dimensions
| Ground Clearance | 7 in |
|---|---|
| Height - Top of Cab | 95 in |
| Length of Track on Ground | 53 in |
| Tail Swing Radius | 47 in |
| Width to Outside of Tracks | 40 in |
Undercarriage
| Ground Pressure | 4 psi |
|---|---|
| Number of Track Rollers per Side | 4 |
| Max Travel Speed | 2.4 mph |
| Shoe Size | 10 in |
Boom/Stick Excavator Option 1
| Max Digging Depth | 98 in |
|---|---|
| Max Reach Along Ground | 162 in |
| Max Vertical Wall Digging Depth | 66 in |
| Max Loading Height | 110 in |
| Max Cutting Height | 154 in |
Bucket
| Reference Bucket Capacity | 0.10 yd³ |
|---|
Swing Mechanism
| Swing Speed | 10 rpm |
|---|
Boom/Stick Excavator Option 2
| Max Digging Depth | 103 in |
|---|---|
| Max Cutting Height | 158 in |
| Max Loading Height | 115 in |
| Max Vertical Wall Digging Depth | 73 in |
| Max Reach Along Ground | 169 in |
