Gehl
Komatsu
PC20R-8
Mini Excavator
47 specifications
1 / 5
Image 1 of 5
Specifications
32 data points
Operating Specifications
| Operating Weight | 6,875 lb |
|---|---|
| Fuel Capacity | 10.9 gal |
| Hydraulic Pump Flow Capacity | 46.1 gal/min |
| Hydraulic System Fluid Capacity | 7.2 gal |
| Hydraulic System Relief Valve Pressure | 3,263 psi |
| Operating Voltage | 12 V |
| Alternator Supplied Amperage | 71 A |
Engine
| Engine Model | Yanmar 3TNV88-NNS A Tier II |
|---|---|
| Displacement | 98 in³ |
| Power Measured @ | 2,500 rpm |
| Net Power | 29.2 hp |
| Number of Cylinders | 3 |
Dimensions
| Ground Clearance | 11 in |
|---|---|
| Height - Top of Cab | 95 in |
| Length of Track on Ground | 57 in |
| Tail Swing Radius | 50 in |
Undercarriage
| Ground Pressure | 5 psi |
|---|---|
| Number of Track Rollers per Side | 4 |
| Max Travel Speed | 2.9 mph |
| Shoe Size | 12 in |
Boom/Stick Excavator Option 1
| Max Digging Depth | 109 in |
|---|---|
| Max Reach Along Ground | 190 in |
| Max Vertical Wall Digging Depth | 79 in |
| Max Loading Height | 125 in |
| Max Cutting Height | 176 in |
Bucket
| Reference Bucket Capacity | 0.20 yd³ |
|---|
Swing Mechanism
| Swing Speed | 10 rpm |
|---|
Boom/Stick Excavator Option 2
| Max Digging Depth | 120 in |
|---|---|
| Max Cutting Height | 182 in |
| Max Loading Height | 131 in |
| Max Vertical Wall Digging Depth | 88 in |
| Max Reach Along Ground | 199 in |
