Gehl
Bobcat
773
Skid Steer Loader
17 specifications
1 / 5
Image 1 of 5
Specifications
23 data points
Operating Specifications
| Operating Weight | 4,400 lb |
|---|---|
| Max Speed | 6.9 mph |
| Fuel Capacity | 8.6 gal |
| Hydraulic System Fluid Capacity | 8.1 gal |
| Tire Size | 8.50x15 |
| Operating Voltage | 12 V |
| Alternator Supplied Amperage | 40 A |
Engine
| Engine Model | 3TNE88 diesel |
|---|---|
| Displacement | 100 in³ |
| Power Measured @ | 3,000 rpm |
| Gross Power | 36.0 hp |
Hydraulic System
| Pump Flow Capacity | 14.4 gal/min |
|---|
Dimensions
| Ground Clearance | 6 in |
|---|---|
| Height - Top of Cab | 71 in |
| Wheelbase | 35 in |
| Width Over Tires | 49 in |
| Reach at Max Lift and Dump | 23 in |
| Length with Bucket | 115 in |
| Clearance at Max Lift and Dump | 85 in |
| Turning Radius from Center - inc bucket | 34 in |
| Turning Radius from Center - machine rear | 27 in |
| Length w/o Bucket | 89 in |
Loader
| Operating Load Rating | 1,050 lb |
|---|
