Gehl
Bobcat
773
Skid Steer Loader
17 specifications
1 / 5
Image 1 of 5
Specifications
23 data points
Operating Specifications
| Operating Weight | 4,600 lb |
|---|---|
| Max Speed | 6.9 mph |
| Fuel Capacity | 8.6 gal |
| Hydraulic System Fluid Capacity | 8.1 gal |
| Tire Size | 10.00x16.5 |
| Operating Voltage | 12 V |
| Alternator Supplied Amperage | 40 A |
Engine
| Engine Model | 3TNE88 diesel |
|---|---|
| Displacement | 100 in³ |
| Power Measured @ | 3,000 rpm |
| Gross Power | 36.0 hp |
Hydraulic System
| Pump Flow Capacity | 14.4 gal/min |
|---|
Dimensions
| Ground Clearance | 8 in |
|---|---|
| Height - Top of Cab | 73 in |
| Wheelbase | 37 in |
| Width Over Tires | 53 in |
| Reach at Max Lift and Dump | 25 in |
| Length with Bucket | 119 in |
| Clearance at Max Lift and Dump | 88 in |
| Turning Radius from Center - inc bucket | 36 in |
| Turning Radius from Center - machine rear | 40 in |
| Length w/o Bucket | 90 in |
Loader
| Operating Load Rating | 1,260 lb |
|---|
