Gehl
Bobcat
773
Skid Steer Loader
17 specifications
1 / 5
Image 1 of 5
Specifications
26 data points
Operating Specifications
| Operating Weight | 4,600 lb |
|---|---|
| Max Speed | 6.5 mph |
| Fuel Capacity | 12.5 gal |
| Hydraulic System Fluid Capacity | 8.1 gal |
| Tire Size | 10.00x16.5 HD |
| Operating Voltage | 12 V |
| Alternator Supplied Amperage | 40 A |
Engine
| Engine Model | 4TNV88 |
|---|---|
| Displacement | 134 in³ |
| Power Measured @ | 2,600 rpm |
| Gross Power | 46.0 hp |
Hydraulic System
| Pump Flow Capacity | 16.5 gal/min |
|---|
Dimensions
| Ground Clearance | 8 in |
|---|---|
| Height - Top of Cab | 72 in |
| Wheelbase | 37 in |
| Width Over Tires | 53 in |
| Reach at Max Lift and Dump | 23 in |
| Length with Bucket | 117 in |
| Clearance at Max Lift and Dump | 85 in |
| Turning Radius from Center - inc bucket | 35 in |
| Turning Radius from Center - machine rear | 29 in |
| Length w/o Bucket | 91 in |
Loader
| Bucket Capacity | 0.60 yd³ |
|---|---|
| Operating Load Rating | 1,350 lb |
| Tipping Angle | 2,700 ° |
| Operating Width | 53 in |
