Genie
Mec
2647ES
Aerial Lift
21 specifications
1 / 5
Image 1 of 5
Specifications
22 data points
Engine
| System Voltage | 24 V |
|---|---|
| Number of Batteries | 4 |
Dimensions
| Ground Clearance | 4 in |
|---|---|
| Wheelbase | 73 in |
| Overall Length | 8 in |
| Overall Width | 47 in |
| Turning Radius | 91 in |
| Height w/ Rails | 84 in |
| Height w/o Rails | 61 in |
Performance
| Operating Weight | 3,977 lb |
|---|---|
| Max Speed | 2.2 mph |
| Tire Size | 15x5x11 |
| Hydraulic System Fluid Capacity | 3.8 gal |
| Tire Fill/Type | Solid non-marking |
Platform
| Max Platform Height | 241 in |
|---|---|
| Max Platform Weight Capacity | 1,199 lb |
| Platform Inner Length | 89 in |
| Platform Inner Width | 45 in |
| Max Working Height | 319 in |
| Lift Time | 30.0 s |
| Deck Extension | 36 in |
| Lower Time | 33.0 s |
