Gleaner
Rostselmash
ACROS 540
Combine
24 specifications
Gleaner
R65
- Operating Weight w/o Attachment
- 27,600 lb
- Fuel Capacity
- 150.1 gal
- Displacement
- 513 in³
- Power
- 300.0 hp
1 / 5
Image 1 of 5
Specifications
26 data points
Operating Specifications
| Operating Weight w/o Attachment | 27,600 lb |
|---|---|
| Fuel Capacity | 150.1 gal |
| Transmission Type | 4 speed hydrostatic |
Engine
| Engine Model | 84 CTA |
|---|---|
| Displacement | 513 in³ |
| Power Measured @ | 2,100 rpm |
| Number of Cylinders | 6 |
| Power | 300.0 hp |
Dimensions
| Ground Clearance | 20 in |
|---|---|
| Wheelbase | 134 in |
| Overall Length | 304 in |
| Height to Top of Isomount Cab | 142 in |
Cleaning System
| Total Cleaning Area | 7,735 in³ |
|---|---|
| Cleaning Fan Speed - High | 1,150 rpm |
Feeding
| Conveyor Width | 36 in |
|---|
Grain Handling
| Grain Tank Capacity | 2,793.7 gal |
|---|---|
| Unloading Speed | 2.9 bu/sec |
| Unloading Discharge Height | 167 in |
| Unloading Auger Length | 251 in |
Separating
| Separating Area | 4,604 in³ |
|---|---|
| Separator Type | transverse |
Threshing
| Rotor Diameter | 25 in |
|---|---|
| Rotor Length | 88 in |
| Rotor Speed - High | 1,096 rpm |
| Rotor Speed - Low | 200 rpm |
| Concave Area | 837 in³ |
