Grove

GMK4115

All Terrain Crane

Gross Power
422.5 hp
Max Lift Capacity
230,000 lb
Max Speed - Forward
53.0 mph
Transport Width
109 in
All all terrain cranes
Grove GMK4115 All Terrain Crane
1 / 5
Image 1 of 5
Image: jeffmartinauctioneers.com

Specifications

32 data points

Operating Specifications

Operating Specifications specifications
Operating Weight105,822 lb
Tire Size8 tires 16.00R25
Carrier Fuel Capacity106.0 gal
Operating Voltage24 V
Number of Axels4

Dimensions

Dimensions specifications
Transport Width109 in
Transport Height158 in
Transport Length517 in
Width w/ Outriggers Extended276 in
Upper Structure Tail Swing Radius154 in
Carrier Length424 in

Transmission

Transmission specifications
Max Speed - Forward53.0 mph
Transmission TypeDaimler Chrysler G240-16
Number of Forward Gears16
Number of Reverse Gears2

Boom

Boom specifications
Max Lift Capacity230,000 lb
Number of Sections6
Max Height @ Max Raise Angle - no jib2,048 in
Min Height @ Max Raise Angle445 in
Min Working Radius1,379 in
Max Working Radius6,694 in
Height3,228 in

CARRIER ENGINE

CARRIER ENGINE specifications
Gross Power422.5 hp
Max Torque1,549 lb-ft
Torque Measured @1,300 rpm
MakeGrove
Power Measured @1,800 rpm

UPPER STRUCTURE ENGINE

UPPER STRUCTURE ENGINE specifications
Gross Power148.0 hp
MakeGrove
Max Torque428 lb-ft
Torque Measured @1,200 rpm
Power Measured @2,200 rpm
