GroveKrupp
KMK5110
All Terrain Crane
36 specifications
1 / 5
Image 1 of 5
Specifications
37 data points
Operating Specifications
| Operating Weight | 133,232 lb |
|---|---|
| Tire Size | 20.5R25 |
| Carrier Fuel Capacity | 105.7 gal |
| Operating Voltage | 24 V |
| Number of Axels | 5 |
| Alternator Supplied Amperage | 55 A |
| Upper Structure Fuel Capacity | 52.9 gal |
Dimensions
| Transport Width | 119 in |
|---|---|
| Transport Height | 156 in |
| Transport Length | 609 in |
| Width w/ Outriggers Extended | 324 in |
| Upper Structure Tail Swing Radius | 196 in |
| Carrier Length | 529 in |
Transmission
| Max Speed - Forward | 55.4 mph |
|---|---|
| Transmission Type | Allison automatic powershift |
| Number of Forward Gears | 5 |
| Number of Reverse Gears | 1 |
Boom
| Number of Sections | 5 |
|---|---|
| Max Height @ Max Raise Angle - no jib | 1,932 in |
| Min Height @ Max Raise Angle | 516 in |
| Max Elevating Angle | 85 ° |
| Swing Speed | 2 rpm |
| Min Working Radius | 120 in |
| Max Working Radius | 1,740 in |
| Height | 3,360 in |
CARRIER ENGINE
| Gross Power | 496.2 hp |
|---|---|
| Max Torque | 1,475 lb-ft |
| Torque Measured @ | 1,400 rpm |
| Make | Grove |
| Power Measured @ | 2,100 rpm |
UPPER STRUCTURE ENGINE
| Gross Power | 139.5 hp |
|---|---|
| Make | Grove |
| Max Torque | 413 lb-ft |
| Torque Measured @ | 1,600 rpm |
| Power Measured @ | 1,800 rpm |
| Number of cylinders | 6 |
| Cooling System | Water-cooled |
