GMK5240

Specifications

38 data points

Operating Specifications specifications
Operating Weight	134,182 lb
Tire Size	20.5 R25
Carrier Fuel Capacity	105.7 gal
Operating Voltage	24 V
Number of Axels	5
Alternator Supplied Amperage	100 A
Upper Structure Fuel Capacity	52.9 gal

Dimensions specifications
Transport Width	121 in
Transport Height	156 in
Transport Length	616 in
Width w/ Outriggers Extended	328 in
Upper Structure Tail Swing Radius	197 in
Carrier Length	534 in

Boom specifications
Number of Sections	6
Max Height @ Max Raise Angle - no jib	2,364 in
Min Height @ Max Raise Angle	528 in
Max Elevating Angle	82 °
Swing Speed	2 rpm
Min Working Radius	96 in
Max Working Radius	2,160 in
Height	3,864 in
