GroveGrove
RT625
Rough Terrain Crane
38 specifications
Grove
RT58C
- Operating Weight
- 44,120 lb
- Max Lift Capacity
- 36,000 lb
- Max Speed - Forward
- 23.7 mph
- Gross Power
- 124.8 hp
1 / 5
Image 1 of 5
Specifications
30 data points
Operating Specifications
| Operating Weight | 44,120 lb |
|---|---|
| Fuel Capacity | 60.0 gal |
| Tire Size | 17.5X25-20PR |
| Operating Voltage | 12 V |
Engine
| Engine Model | BT5.9L |
|---|---|
| Power Measured @ | 2,800 rpm |
| Gross Power | 124.8 hp |
| Aspiration | turbocharged |
| Torque Measured @ | 1,700 rpm |
| Max Torque | 325 lb-ft |
Dimensions
| Ground Clearance | 13 in |
|---|---|
| Wheelbase | 10 in |
| Transport Width | 96 in |
| Transport Height | 126 in |
| Transport Length | 366 in |
| Width w/ Outriggers Extended | 192 in |
| Upper Structure Tail Swing Radius | 102 in |
| Carrier/Base Length | 229 in |
Transmission
| Max Speed - Forward | 23.7 mph |
|---|---|
| Number of Forward Gears | 6 |
| Number of Reverse Gears | 6 |
| Transmission Type | remote mounted powershift |
Boom
| Max Lift Capacity | 36,000 lb |
|---|---|
| Max Height @ Max Raise Angle - no jib | 720 in |
| Min Height @ Max Raise Angle | 300 in |
| Max Elevating Angle | 75 ° |
| Number of Sections | 3 |
| Swing Speed | 3 rpm |
| Min Operating Radius | 120 in |
| Max Operating Radius | 660 in |
