GroveGrove
RT625
Rough Terrain Crane
38 specifications
Grove
RT750
- Operating Weight
- 80,700 lb
- Max Lift Capacity
- 100,000 lb
- Max Speed - Forward
- 20.4 mph
- Gross Power
- 199.9 hp
1 / 5
Image 1 of 5
Specifications
34 data points
Operating Specifications
| Operating Weight | 80,700 lb |
|---|---|
| Fuel Capacity | 60.0 gal |
| Tire Size | 29.5X25-28PR |
| Operating Voltage | 12 V |
| Hydraulic System Fluid Capacity | 154.0 gal |
Engine
| Engine Model | 6BTA 5.9L |
|---|---|
| Displacement | 360 in³ |
| Power Measured @ | 2,500 rpm |
| Gross Power | 199.9 hp |
| Number of Cylinders | 6 |
| Aspiration | turbocharged |
| Torque Measured @ | 1,500 rpm |
| Max Torque | 600 lb-ft |
| Engine Make | Cummins |
Dimensions
| Ground Clearance | 19 in |
|---|---|
| Wheelbase | 13 in |
| Transport Width | 131 in |
| Transport Height | 146 in |
| Transport Length | 523 in |
| Width w/ Outriggers Extended | 281 in |
| Upper Structure Tail Swing Radius | 165 in |
| Carrier/Base Length | 308 in |
Transmission
| Max Speed - Forward | 20.4 mph |
|---|---|
| Number of Forward Gears | 6 |
| Number of Reverse Gears | 6 |
| Transmission Type | full powershift |
Boom
| Max Lift Capacity | 100,000 lb |
|---|---|
| Max Height @ Max Raise Angle - no jib | 1,320 in |
| Min Height @ Max Raise Angle | 420 in |
| Max Elevating Angle | 75 ° |
| Number of Sections | 4 |
| Swing Speed | 3 rpm |
| Min Operating Radius | 120 in |
| Max Operating Radius | 1,200 in |
