Grove
Terex
A600
Rough Terrain Crane
31 specifications
Grove
RT890E
- Operating Weight
- 115,976 lb
- Max Lift Capacity
- 180,000 lb
- Max Speed - Forward
- 21.8 mph
- Gross Power
- 275.0 hp
1 / 5
Image 1 of 5
Specifications
35 data points
Operating Specifications
| Operating Weight | 115,976 lb |
|---|---|
| Fuel Capacity | 72.2 gal |
| Tire Size | 29.5x25-34bias |
| Operating Voltage | 12 V |
| Hydraulic System Fluid Capacity | 262.9 gal |
Engine
| Engine Model | QSB 6.7L |
|---|---|
| Displacement | 409 in³ |
| Power Measured @ | 2,500 rpm |
| Gross Power | 275.0 hp |
| Number of Cylinders | 6 |
| Aspiration | turbocharged |
| Torque Measured @ | 1,500 rpm |
| Max Torque | 728 lb-ft |
| Engine Make | Cummins |
Dimensions
| Ground Clearance | 15 in |
|---|---|
| Wheelbase | 14 in |
| Transport Width | 132 in |
| Transport Height | 149 in |
| Transport Length | 551 in |
| Width w/ Outriggers Extended | 288 in |
| Carrier/Base Length | 339 in |
Transmission
| Max Speed - Forward | 21.8 mph |
|---|---|
| Max Speed - Reverse | 21.8 mph |
| Number of Forward Gears | 6 |
| Number of Reverse Gears | 6 |
| Transmission Type | full rangeshift |
Boom
| Max Lift Capacity | 180,000 lb |
|---|---|
| Max Height @ Max Raise Angle - no jib | 1,704 in |
| Min Height @ Max Raise Angle | 456 in |
| Max Elevating Angle | 78 ° |
| Number of Sections | 5 |
| Swing Speed | 2 rpm |
| Min Operating Radius | 120 in |
| Max Operating Radius | 1,500 in |
| Height | 2,856 in |
