GroveGrove
RT980
Rough Terrain Crane
39 specifications
Grove
RT9130E
- Operating Weight
- 174,034 lb
- Max Lift Capacity
- 260,000 lb
- Max Speed - Forward
- 15.0 mph
- Gross Power
- 300.4 hp
1 / 5
Image 1 of 5
Specifications
34 data points
Operating Specifications
| Operating Weight | 174,034 lb |
|---|---|
| Fuel Capacity | 100.2 gal |
| Tire Size | 33.25x29-38bias |
| Operating Voltage | 12 V |
| Hydraulic System Fluid Capacity | 325.0 gal |
Engine
| Engine Model | QSC8.3L diesel |
|---|---|
| Displacement | 507 in³ |
| Power Measured @ | 2,200 rpm |
| Gross Power | 300.4 hp |
| Number of Cylinders | 6 |
| Torque Measured @ | 1,600 rpm |
| Max Torque | 1,000 lb-ft |
Weights
| Counterweight | 40,001 lb |
|---|
Hydraulic System
| Maximum operating pressure | 4,801 psi |
|---|---|
| Pump Flow Capacity | 775.9 gal/min |
Dimensions
| Wheelbase | 16 in |
|---|---|
| Transport Height | 165 in |
| Transport Length | 617 in |
| Width w/ Outriggers Extended | 335 in |
| Upper Structure Tail Swing Radius | 173 in |
| Carrier/Base Length | 384 in |
Transmission
| Max Speed - Forward | 15.0 mph |
|---|---|
| Number of Forward Gears | 6 |
| Number of Reverse Gears | 3 |
| Transmission Type | full powershift |
Boom
| Max Lift Capacity | 260,000 lb |
|---|---|
| Max Height @ Max Raise Angle - no jib | 1,920 in |
| Min Height @ Max Raise Angle | 504 in |
| Max Elevating Angle | 78 ° |
| Number of Sections | 5 |
| Swing Speed | 3 rpm |
| Min Operating Radius | 120 in |
| Max Operating Radius | 1,680 in |
| Height | 3,348 in |
