Grove
JLG
1350SJP
Aerial Lift
27 specifications
1 / 5
Image 1 of 5
Specifications
21 data points
Engine
| Engine Model | Diesel |
|---|---|
| Gross Power | 85.0 hp |
| Fuel Type | diesel |
Dimensions
| Ground Clearance | 12 in |
|---|---|
| Wheelbase | 119 in |
| Overall Length | 40 in |
| Overall Width | 102 in |
| Turning Radius | 181 in |
| Overall Height - mast lowered | 115 in |
Performance
| Operating Weight | 34,000 lb |
|---|---|
| Max Speed | 4.1 mph |
| Tire Size | 385/65D22.5 |
| Hydraulic System Fluid Capacity | 45.0 gal |
| Tire Fill/Type | Pneumatic |
| Fuel Capacity | 35.0 gal |
Platform
| Max Platform Height | 970 in |
|---|---|
| Max Platform Weight Capacity | 500 lb |
| Platform Inner Length | 94 in |
| Platform Inner Width | 36 in |
| Max Working Height | 1,103 in |
| Max Horizontal Reach | 912 in |
