Grove

TMS760

Truck Crane

Operating Weight
87,010 lb
Max Lift Capacity
120,000 lb
Max Speed - Forward
49.8 mph
Displacement
854 in³
All truck cranes
Grove TMS760 Truck Crane
1 / 5
Image 1 of 5
Image: empirecrane.com

Specifications

33 data points

Operating Specifications

Operating Specifications specifications
Operating Weight87,010 lb
Operating Voltage24 V
Tire Sizefront 16.5x22.5 16PR Rear 11x20 14PR
Carrier Fuel Capacity100.0 gal
Upper Structure Hydraulic System Fluid Capacity167.0 gal
Number of Axels4

Dimensions

Dimensions specifications
Ground Clearance12 in
Transport Width132 in
Transport Height139 in
Transport Length540 in
Width w/ Outriggers Extended313 in
Upper Structure Tail Swing Radius158 in
Carrier Length445 in

Transmission

Transmission specifications
Max Speed - Forward49.8 mph
Number of Forward Gears9
Number of Reverse Gears2
Transmission TypeRoadranger

Boom

Boom specifications
Max Lift Capacity120,000 lb
Max Height @ Max Raise Angle - no jib1,476 in
Min Height @ Max Raise Angle552 in
Max Elevating Angle82 °
Number of Sections4
Swing Speed2 rpm
Min Working Radius120 in
Max Working Radius1,320 in

CARRIER ENGINE

CARRIER ENGINE specifications
Gross Power309.8 hp
Displacement854 in³
Power Measured @2,100 rpm
MakeGrove
Max Torque1,005 lb-ft
Torque Measured @1,300 rpm
Number of cylinders6

UPPER STRUCTURE ENGINE

UPPER STRUCTURE ENGINE specifications
MakeGrove
