Grove

TMS800B

Truck Crane

Operating Weight
101,090 lb
Max Lift Capacity
150,000 lb
Max Speed - Forward
49.8 mph
Displacement
854 in³
All truck cranes
Grove TMS800B Truck Crane
1 / 5
Image 1 of 5
Image: manitowoc.com

Specifications

34 data points

Operating Specifications

Operating Specifications specifications
Operating Weight101,090 lb
Operating Voltage24 V
Tire Sizefront 445/65R22.5-20PR rear 12.00R20-18PR
Carrier Fuel Capacity100.0 gal
Upper Structure Hydraulic System Fluid Capacity197.0 gal
Number of Axels4

Weights

Weights specifications
Counterweight12,919 lb

Dimensions

Dimensions specifications
Ground Clearance7 in
Transport Width132 in
Transport Height138 in
Transport Length572 in
Width w/ Outriggers Extended319 in
Upper Structure Tail Swing Radius156 in
Carrier Length445 in

Transmission

Transmission specifications
Max Speed - Forward49.8 mph
Number of Forward Gears9
Number of Reverse Gears2
Transmission TypeRoadranger gearbox

Boom

Boom specifications
Max Lift Capacity150,000 lb
Max Height @ Max Raise Angle - no jib1,596 in
Min Height @ Max Raise Angle552 in
Max Elevating Angle82 °
Number of Sections4
Swing Speed1 rpm
Min Working Radius120 in
Max Working Radius1,320 in

CARRIER ENGINE

CARRIER ENGINE specifications
Gross Power309.8 hp
Displacement854 in³
Power Measured @2,100 rpm
MakeGrove
Max Torque1,005 lb-ft
Torque Measured @1,400 rpm
Number of cylinders6

UPPER STRUCTURE ENGINE

UPPER STRUCTURE ENGINE specifications
MakeGrove
