JCB
JS240L
Excavator
13 specifications
1 / 5
Image 1 of 5
Specifications
40 data points
Operating Specifications
| Operating Weight | 46,297 lb |
|---|---|
| Fuel Capacity | 81.9 gal |
| Hydraulic Pump Flow Capacity | 121.0 gal/min |
| Hydraulic System Fluid Capacity | 70.1 gal |
| Hydraulic System Relief Valve Pressure | 4,550 psi |
| Engine Oil Capacity | 4.4 gal |
| Cooling System Fluid Capacity | 8.3 gal |
| Operating Voltage | 24 V |
| Swing Drive Fluid Capacity | 1.8 gal |
| Alternator Supplied Amperage | 50 A |
Engine
| Engine Model | B5.9C |
|---|---|
| Displacement | 359 in³ |
| Net Power | 150.2 hp |
| Aspiration | Turbocharged and Aftercooled |
| Torque Measured @ | 1,600 rpm |
| Max Torque | 428 lb-ft |
Dimensions
| Ground Clearance | 19 in |
|---|---|
| Height - Top of Cab | 117 in |
| Length of Track on Ground | 144 in |
| Tail Swing Radius | 117 in |
| Width to Outside of Tracks | 119 in |
| Removal Counterweight Clearance | 43 in |
| Digging Depth | 272 in |
| Digging Reach | 272 in |
Undercarriage
| Ground Pressure | 6 psi |
|---|---|
| Track Gauge | 95 in |
| Number of Track Rollers per Side | 9 |
| Max Travel Speed | 3.6 mph |
| Shoe Size | 24 in |
| Number of Shoes per Side | 49 |
| Number of Carrier Rollers per Side | 2 |
| Drawbar Pull | 4,102,763 lb |
Boom/Stick Excavator Option 1
| Max Digging Depth | 274 in |
|---|---|
| Max Reach Along Ground | 393 in |
| Max Loading Height | 261 in |
| Max Cutting Height | 384 in |
| Shipping Length of Unit | 393 in |
| Shipping Height of Unit | 122 in |
Bucket
| Reference Bucket Capacity | 1.40 yd³ |
|---|
Swing Mechanism
| Swing Speed | 12 rpm |
|---|
