HammVibromax
VM66PD
Padfoot Compactor
31 specifications
1 / 5
Image 1 of 5
Specifications
19 data points
Operating Specifications
| Operating Weight | 15,543 lb |
|---|---|
| Fuel Capacity | 46.3 gal |
| Operating Width | 66 in |
Engine
| Engine Model | TD2011 |
|---|---|
| Displacement | 177 in³ |
| Power Measured @ | 2,800 rpm |
| Gross Power | 91.2 hp |
| Number of Cylinders | 4 |
| Make | Deutz |
Dimensions
| Height - Top of Cab | 110 in |
|---|---|
| Width Over Tires | 71 in |
| Turning Radius - Inside | 121 in |
| Overall Length w/o Blade | 185 in |
Drum
| Vibration Frequency 1 | 42 vpm |
|---|---|
| Nominal Amplitude - High | 0 in |
| Pad Height | 3 in |
| Number of Pads | 112 |
| Nominal Amplitude - Low | 0 in |
| Vibration Frequency | 1,800 – 2,520 vpm |
