Hamm
Caterpillar
815K
Soil Compactor
56 specifications
1 / 5
Image 1 of 5
Specifications
38 data points
Operating Specifications
| Operating weight Cabin | 44,082 lb |
|---|---|
| Max Speed | 12.0 mph |
| Fuel Capacity | 74.0 gal |
| Max Weight | 48,458 lb |
| Axle load - front | 29,024 lb |
| Axle load - rear | 15,058 lb |
Engine
| Engine Model | TCD 6.1 L6 |
|---|---|
| Power Measured @ | 2,300 rpm |
| Number of Cylinders | 6 |
| Engine Make | Deutz |
| Emissions Certification | EU Stage IV / EPA Tier 4 |
| Engine Power - ISO 14396 | 214.6 hp |
| Engine power@SAEJ1349 | 214.6 hp |
| Exhaust Gas Recirculation (EGR) | DOC-DPF-SCR |
| Diesel Fuel Tank Capacity - Standard Tank | 8.5 gal |
Dimensions
| Ground Clearance | 15 in |
|---|---|
| Height - Top of Cab | 118 in |
| Wheelbase | 129 in |
| Overall Length | 260 in |
| Turning Radius - Inside | 166 in |
| Loadover height | 93 in |
| Width over cab | 91 in |
| Angle of driving slope-Front | 43 ° |
| Angle of driving slope-Rear | 28 ° |
Drum
| Drum Width | 84 in |
|---|---|
| Centrifugal Force - High | 74,412 lb |
| Drum Diameter | 63 in |
| Nominal Amplitude - High | 0 in |
| Static Linear Load | 29 lb-ft |
| Vibration Frequency 1 | 27 vpm |
| Drum thickness | 2 in |
| Drum Type | smooth |
| Centrifugal Force - Low | 54,404 lb |
| Nominal Amplitude - Low | 0 in |
| Vibration Frequency 2 | 30 vpm |
Steering System
| Steering Method | Articulated steering |
|---|---|
| Oscillating angle | 10 ° |
Speeds
| Size of tyres, rear | AW 23.1-26 12 PR |
|---|
