Specifications
37 data points
Operating Specifications
| Operating Weight | 47,620 lb |
|---|---|
| Fuel Capacity | 93.6 gal |
| Hydraulic Pump Flow Capacity | 118.4 gal/min |
| Hydraulic System Fluid Capacity | 80.6 gal |
| Hydraulic System Relief Valve Pressure | 5,121 psi |
| Engine Oil Capacity | 4.8 gal |
| Operating Voltage | 24 V |
| Alternator Supplied Amperage | 50 A |
| Hydraulic Pump Type | Double Variable |
| Tire Size | 10.00-20 14PR |
| Oscillating Axle Angle | 16 ° |
Engine
| Engine Model | 6D34-TLU2D |
|---|---|
| Displacement | 358 in³ |
| Power Measured @ | 2,000 rpm |
| Net Power | 153.0 hp |
| Number of Cylinders | 6 |
| Aspiration | Turbocharged |
| Torque Measured @ | 1,500 rpm |
| Net Torque | 435 lb-ft |
Dimensions
| Ground Clearance | 15 in |
|---|---|
| Height - Top of Cab | 126 in |
| Wheelbase | 115 in |
| Overall Width | 9 in |
| Tail Swing Radius | 110 in |
| Upper Structure Clearance | 52 in |
| Overall Width - Outriggers Down | 151 in |
Transmission
| Max Travel Speed | 19.6 mph |
|---|---|
| Transmission Type | Fully Hydrostatic 2 stage planetry gear |
| Drawbar Pull | 26,125 lb |
Swing Mechanism
| Swing Speed | 11 rpm |
|---|
Boom/Stick Mobile Excavator Option 1
| Max Digging Depth | 234 in |
|---|---|
| Max Cutting Height | 389 in |
| Max Reach Along Ground | 372 in |
| Max Loading Height | 281 in |
| Shipping Length of Unit | 385 in |
| Shipping Height of Unit | 126 in |
| Max Vertical Wall Dig Depth | 191 in |
