Hidromek
JCB
JS240L
Excavator
13 specifications
1 / 5
Image 1 of 5
Specifications
37 data points
Operating Specifications
| Operating Weight | 49,163 lb |
|---|---|
| Fuel Capacity | 93.6 gal |
| Hydraulic Pump Flow Capacity | 118.4 gal/min |
| Hydraulic System Fluid Capacity | 121.6 gal |
| Hydraulic System Relief Valve Pressure | 5,121 psi |
| Engine Oil Capacity | 4.8 gal |
| Operating Voltage | 24 V |
| Swing Drive Fluid Capacity | 1.4 gal |
| Alternator Supplied Amperage | 50 A |
Engine
| Engine Model | 6D34-TLU2D |
|---|---|
| Displacement | 358 in³ |
| Power Measured @ | 2,000 rpm |
| Net Power | 153.0 hp |
| Aspiration | Turbocharger intercooler |
| Torque Measured @ | 1,500 rpm |
| Max Torque | 435 lb-ft |
Dimensions
| Ground Clearance | 19 in |
|---|---|
| Height - Top of Cab | 118 in |
| Length of Track on Ground | 144 in |
| Tail Swing Radius | 110 in |
| Width to Outside of Tracks | 119 in |
| Removal Counterweight Clearance | 42 in |
Undercarriage
| Track Gauge | 95 in |
|---|---|
| Number of Track Rollers per Side | 9 |
| Max Travel Speed | 3.2 mph |
| Shoe Size | 24 in |
| Number of Shoes per Side | 49 |
| Number of Carrier Rollers per Side | 2 |
| Drawbar Pull | 40,785 lb |
Boom/Stick Excavator Option 1
| Max Digging Depth | 263 in |
|---|---|
| Max Reach Along Ground | 390 in |
| Max Loading Height | 272 in |
| Max Vertical Wall Digging Depth | 202 in |
| Max Cutting Height | 377 in |
| Shipping Length of Unit | 386 in |
| Shipping Height of Unit | 122 in |
Swing Mechanism
| Swing Speed | 11 rpm |
|---|
