Hitachi
180 LCN
- Operating Weight
- 41,942 lb
- Max Digging Depth
- 241 in
- Max Digging Depth
- 259 in
- Net Power
- 121.0 hp
1 / 5
Image 1 of 5
Specifications
49 data points
Operating Specifications
| Operating Weight | 41,942 lb |
|---|---|
| Fuel Capacity | 84.6 gal |
| Hydraulic Pump Flow Capacity | 50.5 gal/min |
| Hydraulic System Fluid Capacity | 58.2 gal |
| Engine Oil Capacity | 4.5 gal |
| Cooling System Fluid Capacity | 4.8 gal |
| Operating Voltage | 24 V |
| Swing Drive Fluid Capacity | 1.7 gal |
| Alternator Supplied Amperage | 70 A |
Engine
| Engine Model | A1-4JJ1X |
|---|---|
| Displacement | 375 in³ |
| Net Power | 121.0 hp |
| Aspiration | Turbocharged intercooler |
| Max Torque | 41 lb-ft |
Dimensions
| Ground Clearance | 18 in |
|---|---|
| Height - Top of Cab | 117 in |
| Length of Track on Ground | 133 in |
| Tail Swing Radius | 98 in |
| Width to Outside of Tracks | 20 in |
| Removal Counterweight Clearance | 41 in |
Undercarriage
| Ground Pressure | 5 psi |
|---|---|
| Track Gauge | 79 in |
| Number of Track Rollers per Side | 2 |
| Max Travel Speed | 3.3 mph |
| Number of Shoes per Side | 46 |
| Number of Carrier Rollers per Side | 7 |
| Drawbar Pull | 764 lb |
Boom/Stick Excavator Option 1
| Max Digging Depth | 241 in |
|---|---|
| Max Reach Along Ground | 352 in |
| Max Loading Height | 254 in |
| Max Vertical Wall Digging Depth | 205 in |
| Max Cutting Height | 366 in |
| Shipping Length of Unit | 355 in |
| Shipping Height of Unit | 122 in |
Swing Mechanism
| Swing Speed | 14 rpm |
|---|
Boom/Stick Excavator Option 2
| Max Digging Depth | 259 in |
|---|---|
| Max Vertical Wall Digging Depth | 220 in |
| Max Cutting Height | 371 in |
| Max Loading Height | 259 in |
| Max Reach Along Ground | 366 in |
| Shipping Length of Unit | 122 in |
| Shipping Height of Unit | 354 in |
Boom/Stick Excavator Option 3
| Max Digging Depth | 278 in |
|---|---|
| Max Cutting Height | 386 in |
| Max Loading Height | 274 in |
| Max Vertical Wall Digging Depth | 247 in |
| Max Reach Along Ground | 386 in |
| Shipping Length of Unit | 134 in |
| Shipping Height of Unit | 354 in |
