Hitachi
Volvo
A35E
Off-Highway Truck
44 specifications
1 / 5
Image 1 of 5
Specifications
36 data points
Operating Specifications
| Fuel Capacity | 185.0 gal |
|---|---|
| Tire Size | 24.00R35 E4 Radial |
| Engine Oil Capacity | 19.0 gal |
| Cooling System Fluid Capacity | 62.1 gal |
| Operating Voltage | 24 V |
| Steering System Fluid Capacity | 26.0 gal |
| Brake/Hoist System Fluid Capacity | 46.0 gal |
Engine
| Engine Model | 12 V Series 2000 |
|---|---|
| Displacement | 1,459 in³ |
| Gross Power | 760.0 hp |
| Net Power | 725.0 hp |
| Number of Cylinders | 12 |
| Torque Measured @ | — |
Weights
| Empty Weight | 94,415 lb |
|---|---|
| Loaded Weight | 239,001 lb |
| Weight Distribution Front - loaded | 32.0 % |
| Weight Distribution Rear - loaded | 68.0 % |
| Weight Distribution Front - empty | 49.0 % |
| Weight Distribution Rear - empty | 51.0 % |
Dimensions
| Ground Clearance | 28 in |
|---|---|
| Wheelbase | 169 in |
| Overall Length | 367 in |
| Overall Width | 175 in |
| Overall Height | 182 in |
| Dump Height | 350 in |
| Dump Ground Clearance | 30 in |
Transmission
| Max Speed | 38.1 mph |
|---|---|
| Transmission Type | Allison M6610 planetary type with integral lock up converter |
| Number of Gears - Forward | — |
| Number of Gears - Reverse | — |
Service Refill Capacities
| Brake/Hoist Hydraulic Tank | 143,984.3 gal |
|---|
Dump
| Dump Angle | 60 ° |
|---|---|
| Raise Time | 11.1 s |
| Lower Time | 14.0 s |
| Load Capacity - heaped | 51.10 yd³ |
| Load Capacity - Struck | 35.99 yd³ |
