Hitachi
Terex
TA27
Off-Highway Truck
46 specifications
1 / 5
Image 1 of 5
Specifications
44 data points
Operating Specifications
| Fuel Capacity | 120.0 gal |
|---|---|
| Tire Size | 18.00R33 |
| Engine Oil Capacity | 8.0 gal |
| Cooling System Fluid Capacity | 55.8 gal |
| Hydraulic System Fluid Capacity | 72.7 gal |
| Operating Voltage | 24 V |
| Steering System Fluid Capacity | 25.7 gal |
| Brake/Hoist System Fluid Capacity | 47.1 gal |
Engine
| Engine Model | Series 60 |
|---|---|
| Displacement | 854 in³ |
| Power Measured @ | 2,100 rpm |
| Gross Power | 525.0 hp |
| Net Power | 486.0 hp |
| Number of Cylinders | 6 |
| Max Torque | 1,750 lb-ft |
| Make | Detroit Diesel |
| Rated Engine Speed | 73 rpm |
Weights
| Operating Weight | 166,230 lb |
|---|---|
| Empty Weight | 73,800 lb |
| Loaded Weight | 166,229 lb |
| Weight Distribution Front - loaded | 34.0 % |
| Weight Distribution Rear - loaded | 66.0 % |
| Weight Distribution Front - empty | 50.0 % |
| Weight Distribution Rear - empty | 50.0 % |
Dimensions
| Ground Clearance | 19 in |
|---|---|
| Wheelbase | 150 in |
| Overall Length | 343 in |
| Overall Width | 191 in |
| Overall Height | 172 in |
| Dump Height | 320 in |
| Dump Ground Clearance | 22 in |
Transmission
| Max Speed | 42.4 mph |
|---|---|
| Transmission Type | Allison H5610A. Fully automatic planetary type with integral lock up converter |
| Number of Gears - Forward | 6 |
| Number of Gears - Reverse | 2 |
Drive System
| Drive Config | 4x2 |
|---|
Service Refill Capacities
| Brake/Hoist Hydraulic Tank | 84,990.7 gal |
|---|
Articulating/Rigid
| Articulating/Rigid | Rigid |
|---|
Dump
| Dump Angle | 60 ° |
|---|---|
| Raise Time | 13.9 s |
| Lower Time | 15.0 s |
| Load Capacity - heaped | 36.30 yd³ |
| Load Capacity - Struck | 27.30 yd³ |
Approximate Weights - Flat Floor
| Body | 1,350 lb |
|---|
