Hitachi

EX2500-6

Mini Excavator

Gross Power
1,400.0 hp
All mini excavators
Hitachi EX2500-6 Mini Excavator
1 / 5
Image 1 of 5
Image: smsmining.com.au

Specifications

43 data points

Operating Specifications

Operating Specifications specifications
Fuel Capacity1,320.8 gal
Hydraulic System Fluid Capacity779.3 gal
Operating Voltage24 V
Alternator Supplied Amperage140 A
Engine Oil Capacity99.9 gal
Cooling System Fluid Capacity125.8 gal
Swing Speed4 rpm

Engine

Engine specifications
Engine ModelQSKTA50-CE
Displacement3,051 in³
Power Measured @1,800 rpm
Gross Power1,400.0 hp
Number of Cylinders16
Aspirationturbocharged

Dimensions

Dimensions specifications
Height - Top of Cab285 in
Length of Track on Ground241 in
Digging Reach672 in
Upper Structure Ground Clearance85 in
Length of Tracks311 in
Height of Tracks81 in

Undercarriage

Undercarriage specifications
Track Gauge198 in
Max Travel Speed1.5 mph
Number of Upper Rollers3
Loading Shovel Operating Weight548,951 lb
Loading Shovel Shoe Width39 in
Loading Shovel Ground Pressure26 psi
Number of Lower Rollers8
Backhoe Shoe Width 139 in
Backhoe Operating Weight - Shoe 1546,747 lb
Backhoe Ground Pressure - Shoe 126 psi
Number of Track Shoes per Side39
Tail Swing Radius248 in

Bucket

Bucket specifications
Reference Bucket Capacity19.70 yd³
Maximum Bucket Capacity21.59 yd³
Minimum Bucket Capacity19.70 yd³

Loading Shovel

Loading Shovel specifications
Max Dig Depth148 in
Max Dig Reach554 in
Max Cutting Height592 in
Max Dump Height408 in

Backhoe Boom / Stick 1

Backhoe Boom / Stick 1 specifications
Max Dig Depth340 in
Max Cutting Height632 in
Max Dump Height407 in
Max Reach on Ground652 in
Max Vertical Wall Dig Depth200 in
