Hitachi
TCM
L16
Wheel Loader
16 specifications
1 / 5
Image 1 of 5
Specifications
27 data points
Operating Specifications
| Operating Weight | 30,358 lb |
|---|---|
| Fuel Capacity | 60.8 gal |
| Tire Size | 20.5-25-12PR L3 |
| Turning Radius | 206 in |
Engine
| Engine Model | BB-6HK1T |
|---|---|
| Displacement | 475 in³ |
| Power Measured @ | 2,300 rpm |
| Net Power | 173.0 hp |
Hydraulic System
| Raise Time | 5.8 s |
|---|---|
| Lower Time | 3.3 s |
| Dump Time | 1.4 s |
Dimensions
| Ground Clearance | 17 in |
|---|---|
| Height - Top of Cab | 128 in |
| Wheelbase | 121 in |
| Width Over Tires | 103 in |
| Reach at Max Lift and Dump | 42 in |
| Length with Bucket on Ground | 296 in |
| Hinge Pin - Max Height | 154 in |
Transmission
| Max Speed - Forward | 21.5 mph |
|---|---|
| Max Speed - Reverse | 23.0 mph |
| Transmission Type | 4-speed full powershift |
| Number of Forward Gears | 4 |
| Number of Reverse Gears | 4 |
Bucket
| Bucket Capacity - heaped | 3.60 yd³ |
|---|---|
| Dump Clearance at Max Raise | 109 in |
| Breakout Force | 28,101 lb |
| Bucket Width | 107 in |
