Hitachi
Komatsu
WA180-3PT
Wheel Loader
41 specifications
1 / 5
Image 1 of 5
Specifications
27 data points
Operating Specifications
| Operating Weight | 37,633 lb |
|---|---|
| Fuel Capacity | 63.5 gal |
| Tire Size | 23.5-25-16PR L3 |
| Turning Radius | 220 in |
Engine
| Engine Model | BB-6HK1T |
|---|---|
| Displacement | 475 in³ |
| Power Measured @ | 2,200 rpm |
| Net Power | 192.0 hp |
Hydraulic System
| Raise Time | 6.0 s |
|---|---|
| Lower Time | 3.3 s |
| Dump Time | 1.4 s |
Dimensions
| Ground Clearance | 19 in |
|---|---|
| Height - Top of Cab | 131 in |
| Wheelbase | 128 in |
| Width Over Tires | 111 in |
| Reach at Max Lift and Dump | 47 in |
| Length with Bucket on Ground | 319 in |
| Hinge Pin - Max Height | 159 in |
Transmission
| Max Speed - Forward | 21.5 mph |
|---|---|
| Max Speed - Reverse | 23.0 mph |
| Transmission Type | 4-speed full powershift |
| Number of Forward Gears | 4 |
| Number of Reverse Gears | 4 |
Bucket
| Bucket Capacity - heaped | 4.20 yd³ |
|---|---|
| Dump Clearance at Max Raise | 114 in |
| Breakout Force | 34,621 lb |
| Bucket Width | 115 in |
