Hitachi
Case
21D
Wheel Loader
43 specifications
1 / 5
Image 1 of 5
Specifications
40 data points
Operating Specifications
| Operating Weight | 7,198 lb |
|---|---|
| Fuel Capacity | 13.2 gal |
| Tire Size | 15.5/60-18-8PR (L2) Tubeless nylon body |
| Hydraulic System Fluid Capacity | 11.1 gal |
| Static Tipping Weight | 4,542 lb |
| Operating Voltage | 12 V |
| Turning Radius | 127 in |
| Engine Oil Fluid Capacity | 1.5 gal |
| Rear Axle Oscillation | 16 ° |
| Alternator Supplied Amperage | 40 A |
| Front Axle/Diff Fluid Capacity | 1.2 gal |
| Rear Axle/Diff Fluid Capacity | 1.2 gal |
| Cooling System Fluid Capacity | 1.6 gal |
Engine
| Engine Model | D1503-DI-T-K2A |
|---|---|
| Displacement | 92 in³ |
| Power Measured @ | 2,500 rpm |
| Net Power | 36.0 hp |
| Number of Cylinders | 3 |
| Aspiration | Turbocharger |
Hydraulic System
| Pump Flow Capacity | 10.9 gal/min |
|---|---|
| Raise Time | 5.0 s |
| Lower Time | 3.2 s |
| Dump Time | 1.2 s |
| Relief Valve Setting | 2,990 psi |
| Pump Type | gear type |
Dimensions
| Ground Clearance | 12 in |
|---|---|
| Height - Top of Cab | 101 in |
| Wheelbase | 76 in |
| Width Over Tires | 66 in |
| Reach at Max Lift and Dump | 33 in |
| Length with Bucket on Ground | 175 in |
| Hinge Pin - Max Height | 120 in |
Transmission
| Max Speed - Forward | 9.3 mph |
|---|---|
| Max Speed - Reverse | 9.4 mph |
| Transmission Type | Hydrostatic transmission automatically controls power and speed with electrically controlled |
Bucket
| Bucket Capacity - heaped | 0.71 yd³ |
|---|---|
| Bucket Capacity - struck | 0.60 yd³ |
| Dump Clearance at Max Raise | 97 in |
| Breakout Force | 8,050 lb |
| Bucket Width | 67 in |
