Hitachi
Kawasaki
80ZV-2
Wheel Loader
47 specifications
1 / 5
Image 1 of 5
Specifications
43 data points
Operating Specifications
| Operating Weight | 65,477 lb |
|---|---|
| Fuel Capacity | 118.9 gal |
| Tire Size | 26.5-25-24PR (L3) |
| Hydraulic System Fluid Capacity | 68.7 gal |
| Static Tipping Weight | 45,504 lb |
| Operating Voltage | 24 V |
| Turning Radius | 268 in |
| Engine Oil Fluid Capacity | 9.0 gal |
| Rear Axle Oscillation | 24 ° |
| Alternator Supplied Amperage | 50 A |
| Front Axle/Diff Fluid Capacity | 22.5 gal |
| Rear Axle/Diff Fluid Capacity | 23.0 gal |
| Cooling System Fluid Capacity | 23.8 gal |
| Transmission Fluid Capacity | 13.3 gal |
Engine
| Engine Model | CC-6WG1X |
|---|---|
| Displacement | 957 in³ |
| Power Measured @ | 1,800 rpm |
| Net Power | 326.0 hp |
| Number of Cylinders | 6 |
| Aspiration | Turbocharger & intercooler |
Hydraulic System
| Pump Flow Capacity | 40.7 gal/min |
|---|---|
| Raise Time | 6.8 s |
| Lower Time | 3.5 s |
| Dump Time | 1.7 s |
| Relief Valve Setting | 2,988 psi |
| Pump Type | gear type |
Dimensions
| Ground Clearance | 17 in |
|---|---|
| Height - Top of Cab | 149 in |
| Wheelbase | 146 in |
| Width Over Tires | 126 in |
| Reach at Max Lift and Dump | 59 in |
| Length with Bucket on Ground | 372 in |
| Hinge Pin - Max Height | 175 in |
Transmission
| Max Speed - Forward | 20.9 mph |
|---|---|
| Max Speed - Reverse | 21.5 mph |
| Transmission Type | Torque converter countershaft type powershift with computer controlled automatic shift and manual shift features included |
| Number of Forward Gears | 4 |
| Number of Reverse Gears | 4 |
Bucket
| Bucket Capacity - heaped | 6.61 yd³ |
|---|---|
| Bucket Capacity - struck | 5.70 yd³ |
| Dump Clearance at Max Raise | 124 in |
| Breakout Force | 53,280 lb |
| Bucket Width | 138 in |
