PW95-1
Excavator
29 specifications
1 / 5
Image 1 of 5
Specifications
55 data points
Operating Specifications
| Operating Weight | 32,408 lb |
|---|---|
| Fuel Capacity | 66.1 gal |
| Hydraulic Pump Flow Capacity | 83.3 gal/min |
| Hydraulic System Fluid Capacity | 47.6 gal |
| Hydraulic System Relief Valve Pressure | 4,975 psi |
| Engine Oil Capacity | 4.3 gal |
| Cooling System Fluid Capacity | 4.8 gal |
| Operating Voltage | 24 V |
| Hydraulic Pump Type | 2 variable displacement axial piston pumps |
| Oscillating Axle Angle | 14 ° |
| Front Diff Fluid Capacity | 2.8 gal |
| Rear Diff Fluid Capacity | 3.6 gal |
Engine
| Engine Model | AI-4JJ1X |
|---|---|
| Displacement | 183 in³ |
| Power Measured @ | 2,200 rpm |
| Net Power | 121.0 hp |
| Number of Cylinders | 4 |
| Aspiration | Turbocharged intercooled |
| Torque Measured @ | 1,800 rpm |
| Net Torque | 296 lb-ft |
Dimensions
| Ground Clearance | 15 in |
|---|---|
| Height - Top of Cab | 124 in |
| Wheelbase | 101 in |
| Overall Width | 8 in |
| Upper Structure Clearance | 48 in |
| Overall Width - Outriggers Down | 133 in |
Transmission
| Max Travel Speed | 21.8 mph |
|---|---|
| Transmission Type | 2 speed power shift transmission and variable displacement axial piston type travel motor |
| Number of Forward Gears | 2 |
| Number of Reverse Gears | 2 |
Bucket
| Reference Bucket Capacity | 0.71 yd³ |
|---|---|
| Maximum Bucket Capacity | 0.90 yd³ |
| Minimum Bucket Capacity | 0.30 yd³ |
Swing Mechanism
| Swing Speed | 14 rpm |
|---|
Boom/Stick Mobile Excavator Option 1
| Max Digging Depth | 182 in |
|---|---|
| Max Cutting Height | 342 in |
| Max Reach Along Ground | 309 in |
| Max Loading Height | 246 in |
| Shipping Length of Unit | 304 in |
| Shipping Height of Unit | 124 in |
| Max Vertical Wall Dig Depth | 162 in |
Boom/Stick Mobile Excavator Option 2
| Max Digging Depth | 199 in |
|---|---|
| Max Cutting Height | 349 in |
| Max Reach Along Ground | 324 in |
| Max Loading Height | 254 in |
| Shipping Height of Unit | 124 in |
| Shipping Length of Unit | 305 in |
| Max Vertical Wall Dig Depth | 179 in |
Boom/Stick Mobile Excavator Option 3
| Max Digging Depth | 219 in |
|---|---|
| Max Cutting Height | 361 in |
| Max Reach Along Ground | 343 in |
| Max Loading Height | 267 in |
| Shipping Height of Unit | 128 in |
| Shipping Length of Unit | 304 in |
| Max Vertical Wall Dig Depth | 197 in |
