Specifications
53 data points
Operating Specifications
| Operating Weight | 38,140 lb |
|---|---|
| Fuel Capacity | 74.0 gal |
| Hydraulic Pump Flow Capacity | 97.3 gal/min |
| Hydraulic System Fluid Capacity | 47.6 gal |
| Hydraulic System Relief Valve Pressure | 4,980 psi |
| Engine Oil Capacity | 4.2 gal |
| Cooling System Fluid Capacity | 5.1 gal |
| Operating Voltage | 24 V |
| Hydraulic Pump Type | 2 variable displacement axial piston pumps |
| Oscillating Axle Angle | 12 ° |
| Front Diff Fluid Capacity | 3.0 gal |
| Rear Diff Fluid Capacity | 3.5 gal |
Engine
| Engine Model | 4BG1XABF |
|---|---|
| Displacement | 264 in³ |
| Power Measured @ | 2,300 rpm |
| Net Power | 121.0 hp |
| Number of Cylinders | 4 |
| Aspiration | turbocharged intercooled |
| Torque Measured @ | 1,800 rpm |
| Net Torque | 330 lb-ft |
Dimensions
| Ground Clearance | 15 in |
|---|---|
| Height - Top of Cab | 120 in |
| Wheelbase | 101 in |
| Overall Width | 8 in |
| Tail Swing Radius | 86 in |
| Upper Structure Clearance | 48 in |
| Overall Width - Outriggers Down | 142 in |
Transmission
| Max Travel Speed | 19.9 mph |
|---|---|
| Transmission Type | 2-gear powershift |
| Number of Forward Gears | 2 |
| Number of Reverse Gears | 2 |
Swing Mechanism
| Swing Speed | 13 rpm |
|---|
Boom/Stick Mobile Excavator Option 1
| Max Digging Depth | 189 in |
|---|---|
| Max Cutting Height | 344 in |
| Max Reach Along Ground | 326 in |
| Max Loading Height | 239 in |
| Shipping Length of Unit | 336 in |
| Shipping Height of Unit | 124 in |
| Max Vertical Wall Dig Depth | 167 in |
Boom/Stick Mobile Excavator Option 2
| Max Digging Depth | 211 in |
|---|---|
| Max Cutting Height | 359 in |
| Max Reach Along Ground | 348 in |
| Max Loading Height | 251 in |
| Shipping Height of Unit | 120 in |
| Shipping Length of Unit | 359 in |
| Max Vertical Wall Dig Depth | 191 in |
Boom/Stick Mobile Excavator Option 3
| Max Digging Depth | 230 in |
|---|---|
| Max Cutting Height | 369 in |
| Max Reach Along Ground | 366 in |
| Max Loading Height | 260 in |
| Shipping Height of Unit | 124 in |
| Shipping Length of Unit | 360 in |
| Max Vertical Wall Dig Depth | 210 in |
