Hitachi
JCB
JS240L
Excavator
13 specifications
.jpg)
1 / 5
Image 1 of 5
Specifications
44 data points
Operating Specifications
| Operating Weight | 47,245 lb |
|---|---|
| Fuel Capacity | 106.5 gal |
| Hydraulic Pump Flow Capacity | 35.7 gal/min |
| Hydraulic System Fluid Capacity | 63.5 gal |
| Engine Oil Capacity | 6.1 gal |
| Cooling System Fluid Capacity | 7.4 gal |
Engine
| Engine Model | 4HK1 |
|---|---|
| Displacement | 317 in³ |
| Power Measured @ | 2,000 rpm |
| Net Power | 160.0 hp |
| Aspiration | Turbocharged air-to-air charge-air cooler |
| Alternator | 50 A |
| Emission Tier Level | EPA Final Tier 4 |
| Battery | 2 |
| Off-Level Capacity | 70.0 % |
Hydraulic System
| Implement - Operating Pressure | 4,975 psi |
|---|---|
| Travel - Operating Pressure | 5,149 psi |
| Controls | Pilot levers short-stroke low-effort hydraulic pilot controls with shutoff lever |
Dimensions
| Ground Clearance | 18 in |
|---|---|
| Overall Height | 126 in |
| Track Gauge | 88 in |
| Counterweight Clearance | 41 in |
| Undercarriage Overall Length | 166 in |
| Cab height | 10 in |
| Center to center - idler to sprocket | 132 in |
Undercarriage
| Number of Track Rollers per Side | 8 |
|---|---|
| Number of Shoes per Side | 46 |
| Number of Carrier Rollers per Side | 2 |
| Drawbar Pull | 45,636 lb |
| Track Adjustment | Hydraulic |
Boom/Stick Excavator Option 1
| Max Digging Depth | 244 in |
|---|---|
| Max Reach Along Ground | 365 in |
| Max Vertical Wall Digging Depth | 210 in |
| Max Cutting Height | 383 in |
| Minimum swing radius | 13 in |
| Max.Dumping Height | 270 in |
| Bucket Digging Force - SAE | 31,698 lb |
| Bucket Digging Force - ISO | 35,520 lb |
| Arm Digging Force - ISO | 31,743 lb |
| Arm Digging Force - SAE | 29,900 lb |
Swing Mechanism
| Swing Speed | 13 rpm |
|---|
Boom/Stick Excavator Option 3
| Overall height | 126 in |
|---|
Performance
| Travel speed low | 2.2 mph |
|---|---|
| Travel Speed - High | 3.5 mph |
