Hitachi
JCB
JS240L
Excavator
13 specifications
1 / 5
Image 1 of 5
Specifications
49 data points
Operating Specifications
| Operating Weight | 43,652 lb |
|---|---|
| Fuel Capacity | 93.8 gal |
| Hydraulic Pump Flow Capacity | 101.5 gal/min |
| Hydraulic System Fluid Capacity | 89.9 gal |
| Hydraulic System Relief Valve Pressure | 4,975 psi |
| Engine Oil Capacity | 6.1 gal |
| Cooling System Fluid Capacity | 6.9 gal |
| Operating Voltage | 24 V |
| Hydraulic Pump Type | 2 variable displacement axial piston pumps |
| Tire Size | 10.00-20 16 PR |
| Oscillating Axle Angle | 14 ° |
| Front Diff Fluid Capacity | 2.6 gal |
| Rear Diff Fluid Capacity | 3.5 gal |
Engine
| Engine Model | AI-4H1X |
|---|---|
| Displacement | 317 in³ |
| Power Measured @ | 2,000 rpm |
| Net Power | 164.0 hp |
| Number of Cylinders | 4 |
| Aspiration | Turbocharged |
| Torque Measured @ | 1,500 rpm |
| Net Torque | 483 lb-ft |
Dimensions
| Ground Clearance | 13 in |
|---|---|
| Height - Top of Cab | 126 in |
| Wheelbase | 109 in |
| Overall Width | 8 in |
| Upper Structure Clearance | 49 in |
| Overall Width - Outriggers Down | 135 in |
Transmission
| Max Travel Speed | 17.1 mph |
|---|---|
| Transmission Type | 2 speed power shift transmission and variable displacement asial piston type travel motor |
| Number of Forward Gears | 2 |
| Number of Reverse Gears | 2 |
Bucket
| Reference Bucket Capacity | 1.10 yd³ |
|---|---|
| Maximum Bucket Capacity | 1.50 yd³ |
| Minimum Bucket Capacity | 0.71 yd³ |
Swing Mechanism
| Swing Speed | 12 rpm |
|---|
Boom/Stick Mobile Excavator Option 1
| Max Digging Depth | 229 in |
|---|---|
| Max Cutting Height | 388 in |
| Max Reach Along Ground | 373 in |
| Max Loading Height | 276 in |
| Shipping Length of Unit | 389 in |
| Shipping Height of Unit | 127 in |
| Max Vertical Wall Dig Depth | 203 in |
Boom/Stick Mobile Excavator Option 2
| Max Digging Depth | 248 in |
|---|---|
| Max Cutting Height | 402 in |
| Max Reach Along Ground | 393 in |
| Max Loading Height | 291 in |
| Shipping Height of Unit | 126 in |
| Shipping Length of Unit | 383 in |
| Max Vertical Wall Dig Depth | 221 in |
