Hitachi
JCB
JS240L
Excavator
13 specifications
_0010)
1 / 5
Image 1 of 5
Specifications
36 data points
Operating Specifications
| Operating Weight | 54,013 lb |
|---|---|
| Fuel Capacity | 84.6 gal |
| Hydraulic Pump Flow Capacity | 112.1 gal/min |
| Hydraulic System Fluid Capacity | 60.8 gal |
| Engine Oil Capacity | 6.1 gal |
| Cooling System Fluid Capacity | 6.9 gal |
| Operating Voltage | 24 V |
| Swing Drive Fluid Capacity | 1.9 gal |
Engine
| Engine Model | AI-4HK1X |
|---|---|
| Power Measured @ | 2,000 rpm |
| Net Power | 163.7 hp |
| Aspiration | Turbocharged |
| Torque Measured @ | 1,500 rpm |
| Max Torque | 483 lb-ft |
| Engine Make | Isuzu |
Dimensions
| Ground Clearance | 18 in |
|---|---|
| Height - Top of Cab | 122 in |
| Length of Track on Ground | 176 in |
| Tail Swing Radius | 79 in |
| Width to Outside of Tracks | 119 in |
| Removal Counterweight Clearance | 41 in |
Undercarriage
| Ground Pressure | 6 psi |
|---|---|
| Track Gauge | 95 in |
| Number of Track Rollers per Side | 8 |
| Max Travel Speed | 3.5 mph |
| Shoe Size | 32 in |
| Number of Shoes per Side | 49 |
| Number of Carrier Rollers per Side | 2 |
Boom/Stick Excavator Option 1
| Max Digging Depth | 263 in |
|---|---|
| Max Reach Along Ground | 384 in |
| Max Loading Height | 283 in |
| Max Vertical Wall Digging Depth | 241 in |
| Max Cutting Height | 396 in |
| Shipping Length of Unit | 355 in |
| Shipping Height of Unit | 122 in |
Swing Mechanism
| Swing Speed | 13 rpm |
|---|
