Hyundai
John Deere
3375
Skid Steer Loader
21 specifications
1 / 5
Image 1 of 5
Specifications
22 data points
Operating Specifications
| Operating Weight | 1,750 lb |
|---|---|
| Max Speed | 3.0 mph |
| Fuel Capacity | 2.2 gal |
| Hydraulic System Fluid Capacity | 11.6 gal |
| Tire Size | 18 8.5-8 |
Engine
| Engine Model | CH25 |
|---|---|
| Power Measured @ | 3,600 rpm |
| Gross Power | 25.0 hp |
Hydraulic System
| Pump Flow Capacity | 8.6 gal/min |
|---|---|
| Relief Valve Pressure | 3,000 psi |
Dimensions
| Ground Clearance | 4 in |
|---|---|
| Height - Top of Cab | 50 in |
| Wheelbase | 28 in |
| Width Over Tires | 41 in |
| Reach at Max Lift and Dump | 20 in |
| Length with Bucket | 80 in |
| Clearance at Max Lift and Dump | 42 in |
| Turning Radius from Center - inc bucket | 47 in |
| Turning Radius from Center - machine rear | 36 in |
| Length w/o Bucket | 61 in |
Loader
| Operating Load Rating | 475 lb |
|---|---|
| Tipping Angle | 950 ° |
