John Deere

3375

Skid Steer Loader

Operating Weight
1,925 lb
Bucket Capacity
0.30 yd³
All skid steer loaders
John Deere 3375 Skid Steer Loader
1 / 5
Image 1 of 5
Image: brokentractor.com

Specifications

21 data points

Operating Specifications

Operating Specifications specifications
Operating Weight1,925 lb
Fuel Capacity6.0 gal
Operating Voltage12 V

Engine

Engine specifications
Engine ModelSeries 220
Displacement42 in³
Power Measured @3,400 rpm
Number of Cylinders3

Hydraulic System

Hydraulic System specifications
Pump Flow Capacity8.0 gal/min
Relief Valve Pressure1,600 psi
Pump TypeOpen-center

Dimensions

Dimensions specifications
Ground Clearance6 in
Height - Top of Cab70 in
Wheelbase32 in
Reach at Max Lift and Dump21 in
Length with Bucket94 in
Clearance at Max Lift and Dump76 in
Length w/o Bucket71 in

Loader

Loader specifications
Bucket Capacity0.30 yd³
Operating Load Rating675 lb
Tipping Angle750 °
Breakout Force1,400 psi
