John Deere
Hyundai
HSL275T
Skid Steer Loader
26 specifications
1 / 5
Image 1 of 5
Specifications
27 data points
Operating Specifications
| Operating Weight | 2,076 lb |
|---|---|
| Max Speed | 4.3 mph |
| Fuel Capacity | 5.0 gal |
| Hydraulic System Fluid Capacity | 18.0 gal |
| Tire Size | 5.70-12 |
| Operating Voltage | 12 V |
| Operating Speed | 4.3 mph |
Engine
| Engine Model | KT17 |
|---|---|
| Displacement | 42 in³ |
| Power Measured @ | 3,400 rpm |
| Gross Power | 17.0 hp |
| Number of Cylinders | 2 |
Hydraulic System
| Pump Flow Capacity | 7.5 gal/min |
|---|---|
| Relief Valve Pressure | 1,500 psi |
| Pump Type | Open-center |
Dimensions
| Ground Clearance | 5 in |
|---|---|
| Height - Top of Cab | 76 in |
| Wheelbase | 30 in |
| Width Over Tires | 36 in |
| Reach at Max Lift and Dump | 14 in |
| Length with Bucket | 96 in |
| Clearance at Max Lift and Dump | 73 in |
| Turning Radius from Center - inc bucket | 46 in |
| Turning Radius from Center - machine rear | 46 in |
Loader
| Bucket Capacity | 0.20 yd³ |
|---|---|
| Operating Load Rating | 600 lb |
| Tipping Angle | 1,200 ° |
