Hyundai
New Holland
E200SR
Excavator
44 specifications
1 / 5
Image 1 of 5
Specifications
65 data points
Operating Specifications
| Operating Weight | 31,967 lb |
|---|---|
| Fuel Capacity | 71.4 gal |
| Hydraulic Pump Flow Capacity | 68.7 gal/min |
| Hydraulic System Fluid Capacity | 55.5 gal |
| Hydraulic System Relief Valve Pressure | 4,690 psi |
| Engine Oil Capacity | 4.9 gal |
| Cooling System Fluid Capacity | 5.9 gal |
| Operating Voltage | 24 V |
| Alternator Supplied Amperage | 50 A |
| Hydraulic Pump Type | 2x Variable Diaplacement Piston |
| Tire Size | 9.00-20-14PR |
| Front Diff Fluid Capacity | 2.7 gal |
| Rear Diff Fluid Capacity | 2.9 gal |
Engine
| Engine Model | D04FD-TAA |
|---|---|
| Displacement | 259 in³ |
| Power Measured @ | 2,000 rpm |
| Gross Power | 119.0 hp |
| Net Power | 105.0 hp |
| Number of Cylinders | 4 |
| Aspiration | Turbocharged |
| Torque Measured @ | 1,700 rpm |
| Net Torque | 328 lb-ft |
Dimensions
| Ground Clearance | 18 in |
|---|---|
| Height - Top of Cab | 125 in |
| Wheelbase | 103 in |
| Overall Width | 8 in |
| Tail Swing Radius | 90 in |
| Upper Structure Clearance | 49 in |
| Overall Width - Outriggers Down | 144 in |
Transmission
| Max Travel Speed | 19.3 mph |
|---|---|
| Transmission Type | Hydrostatic |
| Number of Forward Gears | 2 |
| Number of Reverse Gears | 2 |
Bucket
| Reference Bucket Capacity | 0.80 yd³ |
|---|---|
| Maximum Bucket Capacity | 1.29 yd³ |
| Minimum Bucket Capacity | 0.41 yd³ |
Swing Mechanism
| Swing Speed | 12 rpm |
|---|
Boom/Stick Mobile Excavator Option 1
| Max Digging Depth | 182 in |
|---|---|
| Max Cutting Height | 332 in |
| Max Reach Along Ground | 298 in |
| Max Loading Height | 236 in |
| Shipping Length of Unit | 305 in |
| Shipping Height of Unit | 125 in |
| Max Vertical Wall Dig Depth | 162 in |
Boom/Stick Mobile Excavator Option 2
| Max Digging Depth | 191 in |
|---|---|
| Max Cutting Height | 335 in |
| Max Reach Along Ground | 304 in |
| Max Loading Height | 239 in |
| Shipping Height of Unit | 125 in |
| Shipping Length of Unit | 307 in |
| Max Vertical Wall Dig Depth | 167 in |
Boom/Stick Mobile Excavator Option 3
| Max Digging Depth | 206 in |
|---|---|
| Max Cutting Height | 348 in |
| Max Reach Along Ground | 320 in |
| Max Loading Height | 252 in |
| Shipping Height of Unit | 125 in |
| Shipping Length of Unit | 306 in |
| Max Vertical Wall Dig Depth | 189 in |
Boom/Stick Mobile Excavator Option 4
| Max Digging Depth | 197 in |
|---|---|
| Max Cutting Height | 364 in |
| Max Reach Along Ground | 319 in |
| Max Loading Height | 267 in |
| Shipping Height of Unit | 125 in |
| Shipping Length of Unit | 322 in |
| Max Vertical Wall Dig Depth | 167 in |
