JS240L
Excavator
13 specifications
1 / 5
Image 1 of 5
Specifications
57 data points
Operating Specifications
| Operating Weight | 45,195 lb |
|---|---|
| Fuel Capacity | 81.9 gal |
| Hydraulic Pump Flow Capacity | 116.3 gal/min |
| Hydraulic System Fluid Capacity | 71.4 gal |
| Hydraulic System Relief Valve Pressure | 4,690 psi |
| Engine Oil Capacity | 3.8 gal |
| Cooling System Fluid Capacity | 9.3 gal |
| Operating Voltage | 24 V |
| Alternator Supplied Amperage | 50 A |
| Hydraulic Pump Type | two variable displacement piston pumps |
| Tire Size | 10-20-14PR dual |
| Front Diff Fluid Capacity | 4.3 gal |
| Rear Diff Fluid Capacity | 4.3 gal |
Engine
| Engine Model | B5.9C |
|---|---|
| Displacement | 359 in³ |
| Power Measured @ | 1,950 rpm |
| Gross Power | 166.0 hp |
| Net Power | 153.0 hp |
| Number of Cylinders | 6 |
| Aspiration | turbocharged |
| Torque Measured @ | 1,500 rpm |
| Net Torque | 495 lb-ft |
Dimensions
| Ground Clearance | 15 in |
|---|---|
| Height - Top of Cab | 126 in |
| Wheelbase | 110 in |
| Overall Width | 8 in |
| Tail Swing Radius | 110 in |
| Upper Structure Clearance | 49 in |
| Overall Width - Outriggers Down | 149 in |
Transmission
| Max Travel Speed | 20.6 mph |
|---|---|
| Transmission Type | hydrostatic |
| Drawbar Pull | 23,800 lb |
Bucket
| Reference Bucket Capacity | 1.10 yd³ |
|---|---|
| Maximum Bucket Capacity | 1.80 yd³ |
| Minimum Bucket Capacity | 0.71 yd³ |
Swing Mechanism
| Swing Speed | 13 rpm |
|---|
Boom/Stick Mobile Excavator Option 1
| Max Digging Depth | 216 in |
|---|---|
| Max Cutting Height | 374 in |
| Max Reach Along Ground | 350 in |
| Max Loading Height | 263 in |
| Shipping Length of Unit | 379 in |
| Shipping Height of Unit | 133 in |
| Max Vertical Wall Dig Depth | 197 in |
Boom/Stick Mobile Excavator Option 2
| Max Digging Depth | 231 in |
|---|---|
| Max Cutting Height | 384 in |
| Max Reach Along Ground | 365 in |
| Max Loading Height | 272 in |
| Shipping Height of Unit | 128 in |
| Shipping Length of Unit | 376 in |
| Max Vertical Wall Dig Depth | 215 in |
Boom/Stick Mobile Excavator Option 3
| Max Digging Depth | 252 in |
|---|---|
| Max Cutting Height | 389 in |
| Max Reach Along Ground | 381 in |
| Max Loading Height | 278 in |
| Shipping Height of Unit | 122 in |
| Shipping Length of Unit | 374 in |
| Max Vertical Wall Dig Depth | 229 in |
