Hyundai
JCB
JS240L
Excavator
13 specifications
1 / 5
Image 1 of 5
Specifications
32 data points
Operating Specifications
| Operating Weight | 45,856 lb |
|---|---|
| Fuel Capacity | 89.9 gal |
| Hydraulic Pump Flow Capacity | 116.3 gal/min |
| Hydraulic System Fluid Capacity | 47.6 gal |
| Hydraulic System Relief Valve Pressure | 5,221 psi |
Engine
| Engine Model | D6BT-C |
|---|---|
| Power Measured @ | 1,950 rpm |
| Net Power | 157.0 hp |
| Torque Measured @ | 1,600 rpm |
| Max Torque | 412 lb-ft |
Dimensions
| Ground Clearance | 19 in |
|---|---|
| Height - Top of Cab | 115 in |
| Length of Track on Ground | 133 in |
| Tail Swing Radius | 109 in |
| Width to Outside of Tracks | 110 in |
| Removal Counterweight Clearance | 42 in |
Undercarriage
| Ground Pressure | 682 psi |
|---|---|
| Track Gauge | 95 in |
| Number of Track Rollers per Side | 9 |
| Max Travel Speed | 3.3 mph |
| Shoe Size | 24 in |
| Number of Carrier Rollers per Side | 2 |
| Drawbar Pull | 42,200 lb |
Boom/Stick Excavator Option 1
| Max Digging Depth | 267 in |
|---|---|
| Max Reach Along Ground | 385 in |
| Max Loading Height | 263 in |
| Max Vertical Wall Digging Depth | 241 in |
| Max Cutting Height | 373 in |
| Shipping Length of Unit | 376 in |
| Shipping Height of Unit | 119 in |
Bucket
| Reference Bucket Capacity | 1.29 yd³ |
|---|
Swing Mechanism
| Swing Speed | 13 rpm |
|---|
