JCB

325T

Compact Track Loader

Operating Weight
12,364 lb
Displacement
269 in³
Gross Power
73.8 hp
All compact track loaders
JCB 325T Compact Track Loader
1 / 5
Image 1 of 5
Image: wpeequipment.ca

Specifications

41 data points

Operating Specifications

Operating Specifications specifications
Operating Weight12,364 lb
Fuel Capacity27.3 gal
Hydraulic System Fluid Capacity14.6 gal
Cooling System Fluid Capacity5.9 gal
Engine Oil Capacity4.0 gal

Engine

Engine specifications
Engine ModelEcoMAX TCAE-55
Displacement269 in³
Power Measured @2,400 rpm
Gross Power73.8 hp
AspirationLiquid
Torque Measured @1,200 rpm
Alternator95 A
Emissions CertificationEPA-T4F (EU St3B)
Cooling systemLiquid
Battery12 V
Peak Torque295 lb-ft
FuelDiesel
Engine oil service interval hours500

Dimensions

Dimensions specifications
Ground Clearance9 in
Height - Top of Cab83 in
Wheelbase83 in
Width Over Tracks76 in
Length with Bucket150 in
Dump Height90 in
Angle of departure29 °
Dump angle42 °
Loadover height114 in
Reach @ ground level44 in
Pin height126 in
Dig Depth394 in
Max. reach @ full height52 in
Rollback @ ground30 °

Transmission

Transmission specifications
Travelling speed7.7 / 12.5

General Specifications

General Specifications specifications
Operating Width IN. (CM)75 (190) — Starting 2021 Model Year
Engine Power HP (KW)74 (55) — Starting 2021 Model Year
Rated Operating Capacity LBS (KG) 50%3,201 (1,452) — Starting 2020 Model Year

Loader

Loader specifications
Bucket Capacity0.60 yd³
Tipping Angle9,145 °
Operating Load11,003 lb
Breakout Force—
Bucket Width75 in
