JCB

8052

Mini Excavator

Operating Weight
11,466 lb
Max Digging Depth
157 in
Gross Power
47.8 hp
Net Power
46.5 hp
All mini excavators
JCB 8052 Mini Excavator
1 / 5
Image 1 of 5
Image: smartbuy.alibaba.com

Specifications

34 data points

Operating Specifications

Operating Specifications specifications
Operating Weight11,466 lb
Fuel Capacity18.5 gal
Hydraulic Pump Flow Capacity33.0 gal/min
Hydraulic System Fluid Capacity17.7 gal
Hydraulic System Relief Valve Pressure3,626 psi
Operating Voltage12 V
Alternator Supplied Amperage55 A
Engine Oil Capacity1.4 gal
Cooling System Fluid Capacity2.2 gal

Engine

Engine specifications
Engine Model404-22
Displacement134 in³
Power Measured @2,600 rpm
Gross Power47.8 hp
Net Power46.5 hp
Number of Cylinders4
Torque Measured @2,000 rpm
Max Torque104 lb-ft

Dimensions

Dimensions specifications
Ground Clearance15 in
Height - Top of Cab102 in
Tail Swing Radius52 in
Width to Outside of Tracks79 in
Removal Counterweight Clearance25 in

Undercarriage

Undercarriage specifications
Ground Pressure5 psi
Number of Track Rollers per Side5
Max Travel Speed2.7 mph
Shoe Size16 in

Boom/Stick Excavator Option 1

Boom/Stick Excavator Option 1 specifications
Max Digging Depth157 in
Max Reach Along Ground239 in
Max Vertical Wall Digging Depth96 in
Max Loading Height162 in
Shipping Length of Unit190 in
Max Cutting Height219 in
Shipping Height of Unit102 in

Swing Mechanism

Swing Mechanism specifications
Swing Speed10 rpm
